Push To Exit Button Wiring Diagram
Push to exit button by enforcer brandmotion sensors. Electromagnetic lock or a fail safe strike the strike is polarity insensitive push button nc depressing the push button or activating the keypad would open the circuit stopping the flow of electricity and causing the magnet or strike to release.
Installation Operating Instructions 4399 Exit Button
Two are for the application of constant power and two are for control of the magnetic lock.
Push to exit button wiring diagram. Wiring diagram button template product overview videos all essex videos. Wiring instructions fail safe strike with button and keypad wired in series. Due to their motion sensor they can trigger motion and thus unlock the door right when you walk up to the door to exit the space.
The contacts are ul listed with 10 amp capacity. You could also use a wireless receiver and transmitter to control break or make the loop. Essex electronics stainless steel vandal resistant request to exit buttons can be used to control an automatic door electric lockstrike magnetic lock or any electrically controlled device.
The dpst contacts switch when the button is depressed and return when it is released. They are mounted right over the door at the inside of the door frame. L the schematic or line diagram includes all the components of the control circuit and indicates their.
The model pb5 is a spring loaded momentary 2 diameter illuminated exit button mounted on a stainless steel single gang outlet box cover. Motion sensors can take over the job of push to exit buttons. Typical wiring diagrams for push button control stations 3 genera information at each circuit is illustrated with a control circuit continued schematic or line diagram and a control station wiring diagram.
Using a wireless transmitter and receiver to release an electromagnetic lock. Single gang 2 square push button spdt or dpdt. The entry switch could be a key switch keypad or other access control device.
Bring the wire from the common on the push button to the negative on the magnetic lock 24. Wiring diagram electromagnetic door lock em lock push button power supply 12v carane ngonek kunci magnet. Figure 1 shows the color coded identification of the wires and a typical wiring diagram showing a power supply motion detector push button and magnalock so as to comply with the boca code for access controlled egress doors.
Connect an extra piece of wire to the positive on the magnetic lock 25. The exit switch could be a palm button touch bar or motion sensor.
